Technical characteristics
Connection
- Contact type: 4 NO
- Number of contacts: 4
- Flexible conductor cross-section: 1.5 – 16 mm²
- Rigid conductor cross-section: 1.5 – 25 mm²
Current / temperature
- Rated current: 40 A
- Rated operational current at AC3: 25 A
Capacity
- Number of modules: 3
Frequency
- Frequency: 50 – 50 Hz
Voltage
- Rated impulse withstand voltage Uimp: 4000 V
- Rated insulation voltage Ui: 440 V
- Rated voltage Ue: 400 – 400 V
- Control voltage AC: 230 – 230 V
- Control voltage DC: 0 – 0 V
Operating conditions
- Operating temperature: -10 – 50 °C
- Storage/transport temperature: -40 – 80 °C
Use
- Utilization category: AC-7a/AC-7b
Lifespan
- Maximum number of mechanical operations: 100000
- Electrical lifespan in number of cycles: 30000
Power
- Total power loss at In: 14.30 W
- Inrush power consumption: 62.50 VA
Dimensions
- Height: 85 mm
- Width: 54 mm
- Depth: 60 mm
Configuration
- Number of NO contacts: 4
- Number of NC contacts: 0
- With manual override switch: No
