Technical characteristics
Connection
- Contact type: 4 NO
- Number of contacts: 4
- Flexible conductor cross-section: 1 – 6 mm²
- Rigid conductor cross-section: 1 – 10 mm²
Current / temperature
- Rated current: 25 A
- Acceptable rated operational current at AC3: 8.5 A
Capacity
- Number of modules: 2
Frequency
- Frequency: 50 – 50 Hz
Voltage
- Rated impulse withstand voltage Uimp: 4000 V
- Rated insulation voltage Ui: 440 V
- Rated voltage Ue: 400 – 400 V
- Control voltage AC: 230 – 230 V
- Control voltage DC: 0 – 0 V
Operating conditions
- Operating temperature: -10 – 50 °C
- Storage/transport temperature: -40 – 80 °C
Use
- Utilization category: AC-7a/AC-7b
Lifespan
- Maximum number of mechanical operations: 100000
- Electrical lifespan in number of cycles: 30000
Power
- Total power loss under IN: 9 W
- Inrush consumption: 3.20 VA
Dimensions
- Height: 83 mm
- Width: 35.75 mm
- Depth: 60 mm
Configuration
- Number of NO contacts: 4
- Number of NC contacts: 0
- With manual override switch: No
Installation, mounting
- Tightening torque: 1.20 Nm
